Vacuum Steam Generator GV ETNA 4.1 – Made in Italy

Vacuum Steam Generator GV ETNA 4.1 – Made in Italy

Description

  • Stainless steel body AISI 304
  • Ready steam warning lamp.
  • Low-level water lamp indicator.
  • The boiler is refilled continuously.
  • Switch for using chemicals and detergents mixed with steam.
  • Device for cleaning hot water mixed with steam.
  • Washable filter.
  • Flex hose 4 m.
  • Recovery tank capacity 64 L.
  • Drain hose system.
  • Steam regulation.
  • Max steam pressure/temperature/ Steam production : 7 bar/165° C/3,25 kg/h 7 bar/165° C/3,25 kg/h B
  • Boiler absorbed power : 3000 W/230V ~ 50Hz (Ph 1) 3000 W/230V ~ 50Hz (Ph 1)
  • Vacuum motor absorbed power : 1200 W 1200 W
  • Column depression/Air flow : 20.39 kPa/220 m³/h 20.39 kPa/220 m³/h
  • Water tank/detergent tank capacity : 5 l/5 l

Please Refer to Product Images, Product Video & Product Technical Data Sheet For More Information.

Technical Data SheetVideo
Inquire Now
PRODUCT OVERVIEW

Unlimited autonomy thanks to the continuous power supply of the boiler, which enables water top-ups in the tank without having to stop the machine or interrupt work. Discharge pipe to quickly drain dirty water collected without removing the head. Two-stage bypass vacuum motor with cyclone effect. Fields of applications Steam system: Food & beverage (food industry, catering, beverage, winery). Hospitality, community & healthcare (hospitality, buildings cleaning, spa & sport, education & community, healthcare). Industry (industry, transportation, car washers, car dealers). New simple and intuitive control panel, quick-coupling steam gun, main ON/OFF switch with lamp, boiler ON/OFF switch with lamp, steam/detergent regulator/selector, steam flow rate regulator, steam ready warning lamp, low level water indicator lamp with buzzer, steam pressure gauge. Gun with integrated start-up control, adjustment of the vacuum power and steam function activation key. Equipped with 3 pumps: boiler, detergent and water. Maximum safety thanks to the 2 safety thermostats, 1 pressure switch and 1 mechanical maximum pressure valve. Fields of applications Steam system: Food & beverage (food industry, catering, beverage, winery). Hospitality, community & healthcare (hospitality, buildings cleaning, spa & sport, education & community, healthcare). Industry (industry, transportation, car washers, car dealers).

View Product Catalogue
